I posted a link to this in the interior section but thought it was worth putting here as some of the "S" guys may not venture into the interior.

This is a post from 2007 by Stirling of the UK Jaguar forum giving some very intresting info on the S Type development and history.

Kudos to Stirling.


Frederick’s recent thread about the current Jaguar S-Type being in many senses the last true British classic has prompted me to get on with putting together this post on the genesis of the model. It is taken from a special supplement which came out with Car magazine on the eve of the S-Type going on sale in March 1999. The part I’ve reproduced here concentrates on the evolution of the model, and it is of great interest for several reasons. Firstly, it makes it quite clear that the S-Type is the last project left over from the glory days of Jaguar under Sir William Lyons and F.R.W. ‘Lofty’ England. It was Lofty England’s plan for a successor to the Mark 2 which was revived under Ford – England had even specified that the proposed model should be built at Castle Bromwich where, of course, they have eventually ended up being built thirty-odd years later. This fact ought to put to rest any further suggestions that the concept of the S-Type was a Ford one – it was a long standing Jaguar project finally given life by Ford’s investment in the company - and the development and set-up costs of the S-Type came solely from profits made by Jaguar themselves.

Secondly, the article demolishes the idea that the Jaguar S-Type was made up from existing Ford parts bin components, or that it was designed by other than Jaguar design teams. The article makes clear that the only connection with Lincoln was the fact that an entirely new platform - NOT an existing Ford one - was developed specifically to be shared by Jaguar’s new S-Type and Lincoln’s new LS. Apart from that the bottom and crankshaft of the S-Type’s V6 engine is shared with the Duratee, but the rest of it was developed by Jaguar’s engineers – the V8 version being entirely Jaguar. Again, this is no different from Lofty England’s plans for a Mark 2 replacement nearly 40 years ago – ‘the engine and transmission would be based on bought-out items.’ The idea that today’s S-Type is therefore somehow ‘less British’ than earlier Jaguars is therefore a non-starter.

Thirdly, the amount of thought which went into the design of the new S-Type is detailed below. Of particular interest is the care that was taken to combine traditional Jaguar design cues with the latest technological advances. It always annoys me to read the S-Type’s appearance being described as ‘retro’. It’s my view that, if Jaguar had had the money to implement Lofty England’s plan for a new Mark 2 over thirty years ago, then that level of Jaguar would have evolved by today into something not unlike the appearance of the current S-Type. Look at today’s XJ’s – they’re a natural evolution of 1968’s original XJ6 – and I believe that if Jaguar had had the money to continue a more compact model at the time that it too would have evolved as a recognisable descendent of the Mark 2. So today’s S-Type’s no more ‘retro’ than today’s version of the XJ – or, for that matter, the BMW’s an Mercedes which perpetuate design cues peculiar to their respective marques.

So, I hope this post might stop future ill-informed suggestions that the current S-Type was a Ford concept, or a Ford parts-bin construction or that it is somehow less genuinely a British Jaguar than those built under Sir William Lyons and Lofty England. Maybe it could best serve that purpose as a ‘sticky’?

__________________________________________________ ___________


Jaguar has been wanting to build a car like this for 20 years. But only now, with a successful XJ and XK, and the resources of Ford, has it been possible to realise its dream. We discover how the S-Type was conceived, and examine the result.




JAGUAR has dreamed of building this car for years. It’s an obvious thing to do: create a model smaller than the imposing XJ-series, and enjoy the twin benefits of competing where the prestige sales volumes are (BMW 5-series, Audi A6, Mercedes E-class) while playing the surefire heritage card.
Heritage card? Of course. It doesn’t mean the new, smaller Jaguar has to be a retro-fest, but it helps massively that Jaguar virtually created the posh-but-slightly-sporty, sub-plutocrat executive sector around 40 years ago. The car that did it, or rather the two cars, were the 2.4 and 3.4. If that means little, then maybe what those cars became in 1959 – the Jaguar Mark 2 – will mean more. That’s the car, and the market sector, Jaguar abandoned in 1968. Now, 30 years later and in a drastically changed world, the junior Jag is back.

So, why has it taken all this time? It hasn’t been for want of imagination. Jaguar chairman Nick Scheele will tell you that shortly after Jaguar got drawn into British Leyland, chief engineer Lofty England proposed a plan. It was for a replacement for the Mark 2, to be built at the rate of 50,000 cars a year, and powered by a 2.5-litre engine. The engine and transmission would be based on bought-out items, and the car would be built at the old Fisher and Ludow body plant at Castle Bromwich.
BL’s directors said no. That market territory belonged to Rover and Triumph. Much later, Ford’s directors said yes. Lofty England’s plan, with the addition of an extra half-litre of engine capacity, has been turned into reality with uncanny accuracy. The reality is called the Jaguar S-Type, and it was one of the biggest stars of last October’s Birmingham motor show.

It’s a striking looking car. It has rear-wheel drive, of course, and it’s available not only with the existing 4.0-litre V8 but also, crucially, with a 2.5-litre 240bhp V6, Jaguar’s first V-configured six-pot. Now, as it goes on sale, we look more deeply behind the car, at the people who created it, the way they did it and the reasons why.

Clearly, the new car looks like a Jaguar. Eighty-five percent of people seeing it for the first time at customer clinics, at which all badges had been removed, correctly identified the S’s maker. Equally clearly, though, the S-Type doesn’t look like a shrunken XJ8: Jaguar has not gone for the same-prospect, different sizes approach of its German rivals. It had to be distinct from the bigger cars, unique and younger in its appeal. How to achieve this was something that has exercised Jaguar brainpower in a way it hasn’t been exercised for years.

There was also the question of what to call it. Jaguar’s naming policy to date has not been a model of consistency – it once had a Mark 2 and a Mark 10 in its range simultaneously – so six key Jaguar people mulled over a list of all the old Jaguar names.

“We liked SS,” says Scheele, “but we couldn’t really use it. We looked at the Mark idea, but there was the Lincoln Mark VIII so we veered away from that. We tried 400, as a reference to the 420 and 420G, but it didn’t gel. The S-Type was the last iteration of the Mark 2 idea, if you disregard the 420, so we went with that. It’s the same with XK: if you own such initials, use them.

“S-Type is a name we can move into the future. I’m bored with all the past names. What a hotch-potch!”

Thus was the S-Type named. The problem will be even harder to solve for Jaguar’s next model line, aimed at BMW’s 3-series and currently codenamed X400. Anyone want to take a bet on T-Type?

The reason why Jaguar have taken so long to plug its downrange hole is that it has been seriously strapped for cash. The money continued to haemorrhage after Ford’s takeover, but the bleeding eased after the XJ6’s 1994 re-make and sales renaissance. Since then, helped by the success of the XK8, Jaguar has become profitable. Profitable enough to become a four-range car company – XJ saloon, XK sports car, X200 (the new S-Type) and upcoming X400 – while still living only on the profits from the two ranges sold up to now.

Jaguar is proud the new model programme has been funded from its own profits. However, there has been much Ford resource to help it on its way, not least the fact that Ford US was planning a new Lincoln (the LS, poised for launch as you read this) at the same time as Jaguar was dusting off the Mark-2-for-the-1990’s idea.

This was a godsend for Jaguar, because it allowed both cars to be developed and built on a common platform, saving a stack of money. The vital trick was to keep the two cars distanced in customers’ perceptions: “The Ford board wanted them to be unique,” says X200 chief programme engineer David Szczupak, “so the cars were developed by two separate team, with some engineering groups kept in loose formation.”

“The S-Type doesn’t use Ford bits” – Szczupak chooses his words carefully – “but there are some common parts which are used on both cars. The fuel tank, for example, came from the same drawing and has the same part number, but is made in two different factories.” Another very obvious common part is the crankshaft, shared with the 3.0 litre version of Ford’s Duratee V6 (the 2.5 appears in the Mondeo and Cougar) on which the Jaguar V6’s bottom half is based.

The result of this shared effort is a Jaguar which, under its skin, is like no Jaguar before it. From Mark 10/E-Type to XJ8/XK8, Jaguar’s suspension design changed only in detail. Now, it’s modern thinking exemplified, wide-spaced wishbones, multilinks, passive rear-steer and all. Yet certain vitals haven’t changed: the short front overhang, the 50/50 weight distribution, helped by placing the battery in the boot(Jaguar insisted) and, of course, the rear-wheel drive.

As for engines, the V8 is Jaguar-only, and the V6 has cylinder heads quite unlike the regular Duratee’s. The V6 is made at Cleveland, Ohio, with its Ford relatives, but the two-stage variable inlet-valve timing and three-stage variable inlet manifolding are Jaguar’s own. The 24 valves are operated not by Duratee’s finger followers but by lightweight bucket tappets, just as they are in the V8, and the engine is a much freer breather. This explains both its high peak power (240bhp) and the high revs at which it happens (6800rpm). The LS uses the same head castings, incidentally – Jaguar wasn’t allowed to keep the advantages all to itself – but without the VVT and with a less sporty cam profile.

Clothing all is a body of striking and controversial style. It looks like a Jaguar. But exactly how does it look like a Jaguar? What it is not meant to be is a collection of retro-pastiche details: there was a fine line to be trodden between marque values and schmaltz. “People think we get Andrew Whyte’s Jaguar history book, open a bottle of wine, and look at old Jags,” says design director Geoff Lawson, “but it’s nothing like that.”

Understandably, though, people do look for bits of old Mark 2 in the new S-Type. And it has to be said that the front grille, the fairings for the inner headlights, the curved rear quarter window and the rearward-drooping side-crease give them plenty to go on. Fair enough: BMW has its rear-pillar dog-leg and so-called double-kidney grille. Mercedes, too, has its grille and ribbed tail-lights. Of such things are marque-identifiers made.
In fact, Mercedes, historically, has had two main face-types: the regular grille, and the wide mouth with the three-pointed star in its centre for the sportier cars. And Jaguar, as it happens, has had three: the original, formal squared-off grille still used in squat form in today’s XJ, the horizontal-oval air intake of the D-Type, E-Type and XK8, and the vertical, slatted oval which began with the XK120 and ended with the Mark 2 and old S-Type.

This is the face reborn here, after a long absence. It’s the face of smaller, sportier but still-practical Jaguars, familiar enough to please those who remember, but indicative of a new Jaguar direction even for those who don’t. The new car’s grille lacks a thick central bar, as its inspiration did in all its pre-Mark 2 guises; the historically fastidious will see it as more like a C-Type racer’s version than any other, broader at the top and not a true oval. Why no central bar? Lawson’s eyes turn heavenwards. “The difference between a sense of integrity and a parody of the ethos is very small, but a central bar would have been a parody. We did try it with a piece of tape, but it just looked naff.”

Deep body sides and a (Mark 2-like) domed roof give the S-Type more interior space than an XJ saloon can offer. This is important, because people are larger nowadays. Surprisingly, the wheelbase is longer, too, even though the bonnet and boot are shorter relative to the passenger compartment than they are in the grander car. Despite this, Lawson and the chief architect of the S-Type’s styling, Simon Butterworth, have managed to keep a large ‘dash to axle’ dimension.

“This distance is traditionally long in a Jaguar,” says Lawson, “but as A-pillars move further forward we lose a distinctive Jaguar element. If we’re not careful, it could end up looking generic. We have the front door’s shutline as far back as we can, and we angle the screen pillar to reduce the perception of screen rake.” It’s still a ‘faster’ screen than an XJ’s, though, achieved by pulling the bottom edge forward in the middle and so increasing the curvature.

If designing the outside was tricky, given the need to attract a whole swathe of new buyers without compromising the car’s Jaguarness, then the interior really concentrated the stylists’ minds. “It had to be sporty, not a scaled-down X300 (XJ8) interior, and we had to integrate the satellite-navigation screen. It was,” Lawson is trying to emphasise, “very tough. We needed to make it bolder and fresher, but still with wood, understatement, natural materials. It was really hard.”

“There’s a spitfire-wing motif,” continues Butterworth as we debate the cabin’s Britishness, “a shape which makes a statement across the car.” He points out the centre facia vents as an example, which in an earlier facia design joined the semi-circular centre console in an oval echoing the grille up front. “Just a hint of that remains,” says Butterworth. “We’ve kept the design fairly clean, with a level of symmetry.

“We didn’t want a driver-biased interior. Nor have we put the instruments in port-holes this time, and we haven’t gone the chronographic route.” Butterworth is hinting at the Lexus IS200 and to the car whose upper versions might tread on the S-Type’s toes, the Rover 75. He rejects those cars’ fancy dials. “we’re trying to attract a new customer, so we wanted something clean, clinical and no-nonsense for the instruments. But we’ve still tried to put in as many Jaguar stereotypes as possible.”

The sat-nav screen is important, because it’s a visible indicator of deeper technological cleverness. The sat-nav includes real-time traffic information on its map, courtesy of a Trafficmaster interface, but the S’s techno treat is a voice-activation system for stereo, telephone and climate control. Devised by Visteon, a Ford components subsidiary, its fitment in the S-Type is a world first. Alert the system by pressing a button on the steering wheel, issue your command (it can understand nearly all English-language accents) and you will be obeyed. Just like that.
The world has waited long for the Jaguar S-Type, and expectations are high. It’s a new kind of Jaguar, and rosy memories of Mark 2’s won’t be enough to push it onwards on their own. Nor would Jaguar want them to be, for this is a car intended to build on the delights of driving a BMW 5-series while still feeling like a Jaguar.

Now it’s down to the buyers to decide. And judging by the way the order book has filled since October, they seem to be deciding in its favour.
Last edited by Stirling on Tue Jul 31, 2007 10:29 am, edited 2 times in total.
The future is dark, the present burdensome; only the past, dead and finished, bears contemplation. Those who look upon it have survived it: they are its product and its victors. No wonder, therefore, that men concern themselves with history.


by Stirling � Sat Jul 28, 2007 6:44 pm
In the previous post, Jaguar’s chief architect of the S-Type’s styling, Simon Butterworth, drew attention to the deliberate use of an elliptical ‘spitfire-wing’ shape throughout the S-Type. Examples of this elliptical theme can be seen, as mentioned, in the air vents, but also on the inside and outside door handles, the wood door trims, the centre console (although a lot of these were lost in the ‘facelift’ or series II cars), as well as the shape created by the rear light clusters and the back of the boot lid. Butterworth doesn’t say so in the article, but the reason for the Spitfire wing theme being chosen is that the S-Type is built at Castle Bromwich – the same factory which turned out the iconic Spitfire fighter of WWII, and these design cues are therefore a tribute to one of Britain’s most iconic aircraft on one of Britain’s most iconic motor cars. And what is more emblematic of Britain’s transport heritage than the Spitfire and the Jaguar? All of which goes to bolster’s the S-Type’s right to claim to represent the best of British. In October 1998, Jaguar produced a numbered limited edition commemorative Book for the S-Type’s launch. Bound in heavy brushed-aluminium covers, the book includes the story of the Spitfire connection and a picture of the aircraft being built at Castle Bromwich. It’s interesting to read this history of the factory where our S-Types are built:

__________________________________________________ ___________


SIXTY Years ago, building work started on a ‘shadow’ factory at Castle Bromwich which was to cost £4.6 million and take 18 months to complete. The priority was to produce a fighter plane – the Spitfire – an aircraft which would carve a unique place in aviation history.

The initial planning concept for the factory layout was revolutionary because it utilised motor industry assembly line methods pioneered by car makers. The man in charge, Lord Nuffield, wanted to simplify construction as much as possible. However, despite his best intentions, there were still no completed aeroplanes by May 1940.

Lord Beaverbrook, the newly appointed minister responsible for aircraft production, was keen to make his mark. He promptly demanded an explanation from Nuffield about the lack of progress; Nuffield made the mistake of suggesting that perhaps Beaverbrook would like to take control. The canny newspaper baron accepted the challenge immediately and with considerable speed relocated managers and skilled labour from the Vickers Armstrong Supermarine factory in Southampton. The first Spitfires took off within weeks of the changeover – in time to take part in the ‘Battle of Britain.’

In the immediate post-war years Fisher & Ludlow undertook body pressings for some of the most famous cars of the day, including the Standard Vanguard, Standard 8 and 10, Morris Minor saloon and the razor-edged Triumph Mayflower. Body production continued with a broader range of pressings once Fisher & Ludlow became part of the British Motor Corporation – BMC. Famous marques such as Wolseley, Riley and Austin were added as customers. Besides automotive work, the site also produced washing machines, sinks, vending machines, bicycles, plastic products and central heating radiators.

In 1966, a two-year series of mergers began which involved Jaguar, BMC and subsequently the Leyland Group; the result was the birth of the British Leyland Motor Corporation. Fisher & Ludlow then became Pressed Steel Fisher in the same period.

One outcome of these changes meant that bodyshells for the Jaguar XJ6 and XJS models were pressed alongside those for some Austin and Rover ranges. Jaguar took control of the site in 1980 when all resources were concentrated on body assembly and painting of XJ saloons and XJS sportscars, before delivery to Browns Lane for final assembly. Substantial investment to support the introduction of the XK8 was made in 1996.

The 105 acre site has seen many changes since the first Spitfire left the factory 58 years ago. Now the eagerly awaited S-TYPE is about to emerge with the same sense of immense pride.

A Spitfire production line at Castle Bromwich, where todays Jaguar S-Types are produced:
Last edited by Stirling on Sat Jul 28, 2007 6:49 pm, edited 1 time in total.
The future is dark, the present burdensome; only the past, dead and finished, bears contemplation. Those who look upon it have survived it: they are its product and its victors. No wonder, therefore, that men concern themselves with history.


Stirling Ranking: Team Manager Posts: 1919 Joined: Thu Nov 23, 2006 10:30 am Location: St. Andrews Top






by T2M � Sat Jul 28, 2007 8:43 pm
You have hold of some info there Stirling this is the pic as it was taken


DEANO (to my friends) 13% and 133
52 S-type 3.0 SE Auto, Zircon/Sand Sat Nav 6000k HID conversion kit + loads of bits.



Norri ( and Sterling) Great post! Thanks for sharing this article. Hopefully this will help resolve the heritage of the S Type.
This should be a sticky.
VMV



Thanks very much for providing this glimpse into history. I find it very interesting that our S-Type was built in the same facility that built the WWII Spitfire fighter planes that fascinated me in my youth (along with P51 Mustangs and Messerschmidt ME-109s and Stuka divebombers)....

Some of even the most-respected independent repair shops here in our area view the S-Type as "too Fordsy" (their words). I don't care. I still believe the S-Type is one of the most gorgeous sedans on the planet and I hope we keep ours in the family for many years to come....



Attached is a bit more on the co-developed DEW platform.
.
.
.



Buying my 2003 Jaguar S-type last year brought back some memories of when I was a very young kid staring at the 1967 Jaguar 420 that my dad brought home in 1968. As a kid, I couldn't wait to get inside to see the inside which was adorned with the original collony leather and burled walnut wood. The S-type has many of the same styling elements of the Jaguar line from the 1960's including the curved C-pillars, twin front headlights and a curved hood and trunk. With the styling genius of Sir William Lyons, the Jaguars of the 1960's reflected a cheerful time during the peak of prosperity for the US and Great Britain. Driving a Jag made a statement that you liked silence and control at high speeds as opposed to American cars of the time which rode and handled like the USS Forestall.

As a kid, I remember being disappointed in the Jaguar XJ6, which seemed to look like a Chevy by comparison. To make the car more mass production friendly, the interior of the XJ6 was made stark in comparison with the 1960's sedans. Jaguar dispensed with the wood trim and replaced it with veneer. The trim pieces above the windows disappeared. On the outside, the nice body curves were replaced by straight edges behind the front doors. The vertical grilles were replaced by something resembling a milk crate from Sealtest. You either loved it or hated it. My dad and I hated it. The XJ6 reflected a more somber tone of the days to come. Following the XJ6's introduction, the world would soon be changed by high inflation, looming energy shortages, currency devaluations, deindustrialization, and an awareness that there were limits to prosperity, power and resources. The introduction of the Jaguar XJ12 in 1972 seemed more like an affectation in an increasingly gloomy period rather than a serious effort to produce a performance car. Although XJ12 corrected some of the XJ6's styling deficiencies, it would be short lived. The abominable Series II was being manufactured before the last 1973 models were sold off the lots.

For years, Jaguar buyers did not have the opportunity to have a compact Jaguar sedan. As the article states, Jaguar ran out of the resources necessary to produce a spiritual successor to the Mark 2 series of sedans. It appears that the current Jaguar S-type is the closest thing that we will ever see. Harkening back to the older sedans, there were things I would have done differently from Jaguar's execution. I would have included the following:

- Chromed door handles
- A wire wheel option
- Better chrome trim on the window surrounds
- A chrome strip through the hood's center
-Use of the retro Jaguar wings in owners documentation

Other than that, you can't ask for a better styled car than the 2001-2008 Jaguar S-type. From the inside to the outside, Jaguar finally built a car that reflects its rich styling heritage. I am thankful that I was able to get this car for the price of a used Kia. It is too bad that Ian Callum had to come in and Bangalize Jaguar, something from which it may never fully recover. On the other hand, Jaguar does have 9 lives.



Bravo!



FloridaJag,

Great post, very insightful. I continue to believe that these late-model S-Types (2005-and-newer) offer by far the best bang-for-the-buck of any luxury sedan on the market. Steep depreciation (although very unfortunate for the new car buyer) truly helps the second owner big-time....

And while I love the classic looks of wire wheels, I detest the maintenance. Had 'em on a 1974 Datsun 260Z back in the day, but never again....



I agree that the wire wheels were a pain. Our 1967 model had them. They were a pain in the neck to keep clean, and the old version spokes tended to rust.

On the other hand, the Aluminum wheels on my 2003 model SUCK. They are hard to keep clean as well. The brake dust gets lodged in a small area where the "spoke meets the wheel perimeter. I spend more time cleaning that than I do the rest of the wheel.

I am not sure that I would have gone for wire wheels myself, but these things would have made it tempting....



If the wheels are such a hassle, swap them for some others and sell yours. Or figure what to put on yours so the dust comes off more easily. Or change the pads for ones with far less dust - do some searches because people have said which ones are better



It's not just brake dust that makes wire wheels a pain in the *** to maintain. Rain, road grime, salt, and the elements all take their toll as well....



FloridaJag - my previous post was directed to you, about your comments on brake dust.
Jon89 - and not to you lol - wire wheels are lovely but soooo impractical



Changing the pads is the most practical solution for me.



Akebono are worth considering



Congrats Jag on veteran status.....

Yes, +1 on the Akebono pads... Might be the next for me...



So now I'm old? Oh well. LOL

Thanks, though



Fantastic post norri! Thank you! Just the kind of information I hope to find.

And thank you tbird6 for the additional Ford/Jag info.

I've had to explain more than once that the design was British and not from Ford USA, even to a Brit ex-patriot I know. It certainly settles somes questions and critiques I've received after buying my STR a few years ago. The worst one? From a Connecticut blue-blood 30-something I was introduced to recently:

"Why would anyone buy that Jaguar?!? Isn't that just some f*n front-wheel drive Ford Taurus with a Jag front end slapped on it?"

(So classy.)

Instead of getting offended I just smiled, then briefly and calmly explained the relationship between the LS and the S-type, along with a few commonalities and the many differences.

His reply? "Oh. (Overwhelmed by the facts. Not a car guy.) Well, whatever, it's still a P.O.S. Ford!"

That's OK. I just smiled at his lovely date for the evening, and she gave me a delicious smile back. That wiped the smirk clean off his baby smooth face. Douche-bag. He drove an Audi. That poor car deserved better.



He He... Nice one.... I would have pointed out that Audi's are "Just rebodied VW's" I know, I know, VW is the one that uses Audi stuff, but you get the point...Plus base Audi A4's and A6's are front drive. Quattro is an option. Granted that some models / years the "base" car for North America is Quattro.. Plus, if he drove a A3 or TT, well those are just rebodied Golf's. The Q7 is a Toureg....Again..Audi is more of a "platform sharing" car than Jag...



Classic_Engr:

You should have told him all Jaguars are equipped with seats that magically dissolve the panties off beautiful women. His date evidently knew about this feature as witnessed by her delicious smile. You could have been a real cad in that finest tradition of Jaguar owners and whisked her away when he wasn't looking.

Mike



Norri,

Thanks for that great information. I've always thought the modern S-Type is the spiritual successor to the MKII. They are about the same size and have the same features that make them so attractive. These I would say are the overall looks, performance and driveability.

For example the MKII compared to a modern S-Type.
