Rear Shocks and Bearings
#1
Rear Shocks and Bearings
Guys, I need rear shocks and bearings for my 03 X-Type Base.
The shocks that I am getting are Heavy Duty Series (BE5-6676-H0) AWD Rear (24-066761) at Essex Distributors - Bilstein Shock Absorbers
Bearings can't be replaced so I need new hubs, however I don't know the difference between hub and assembly.
I want to order the parts online to give to my local garage, there is no JAG dealer local and usually cheaper.
So there are the Timken's
Timken Wheel Hub by - JCWhitney
Or the Beck Arnley's
Beck Arnley Wheel BearingOE replacement - JCWhitney
There are many others, but those are full or half assembly to me.
I want the ABS to work after the replacement.
What do you suggest?
Thanks for your direction.
Vic Douse
Avondale, PE
Canada
The shocks that I am getting are Heavy Duty Series (BE5-6676-H0) AWD Rear (24-066761) at Essex Distributors - Bilstein Shock Absorbers
Bearings can't be replaced so I need new hubs, however I don't know the difference between hub and assembly.
I want to order the parts online to give to my local garage, there is no JAG dealer local and usually cheaper.
So there are the Timken's
Timken Wheel Hub by - JCWhitney
Or the Beck Arnley's
Beck Arnley Wheel BearingOE replacement - JCWhitney
There are many others, but those are full or half assembly to me.
I want the ABS to work after the replacement.
What do you suggest?
Thanks for your direction.
Vic Douse
Avondale, PE
Canada
Last edited by Vic Douse; 04-23-2013 at 06:36 PM.
#2
UPDATED LINK
Guys, how about this one?
If link does not work it's GBM 713-0001 at Amazon for $52
Guys, how about this one?
If link does not work it's GBM 713-0001 at Amazon for $52
Last edited by Vic Douse; 04-25-2013 at 06:01 AM.
#3
rear shocks and wheel bearings
Vic that lick did not work at Amazon. and the whitney link showed a
2003 Hyundai Tiburon wheel bearing. Try here "Jaguar Parts" - Jaguar parts and accessories catalog or Here Auto Parts Warehouse | Car Parts & Accessories, Truck Parts, Discount Auto Body Parts Online or here US Auto Parts Network, Inc. - USAutoParts.com I have bought parts at all 3 of the online parts stores and received parts within a few days. all jag parts and all returnable if not satisfied.
2004 X-type 3.0
Respect the Motorcar, and have fun.
2003 Hyundai Tiburon wheel bearing. Try here "Jaguar Parts" - Jaguar parts and accessories catalog or Here Auto Parts Warehouse | Car Parts & Accessories, Truck Parts, Discount Auto Body Parts Online or here US Auto Parts Network, Inc. - USAutoParts.com I have bought parts at all 3 of the online parts stores and received parts within a few days. all jag parts and all returnable if not satisfied.
2004 X-type 3.0
Respect the Motorcar, and have fun.
#4
I just replaced both rear hubs two weekends ago. I ordered from Car Part Kings at the following link:
Car Part Kings - 051-6293 Rear Wheel Hubs
They were drop shipped directly from a Beck Arnley warehouse.
Car Part Kings - 051-6293 Rear Wheel Hubs
They were drop shipped directly from a Beck Arnley warehouse.
#5
Nick, Does your ABS still work after replacement?
My understanding is that the ABS sensor plug is attached to the Wheel knuckle and not the Wheel hub?
Also Nick do you think GMB 713-0001 on Amazon is good. I updated the link again, but it's acting strange.
Thanks
Vic
My understanding is that the ABS sensor plug is attached to the Wheel knuckle and not the Wheel hub?
Also Nick do you think GMB 713-0001 on Amazon is good. I updated the link again, but it's acting strange.
Thanks
Vic
#6
Correct on the ABS sensor, it is not attached to the hub. You will run right up against the sensor when removing the lower caliper bolt but there is just enough room so as not to have to remove the sensor.
I googled "GMB 713-0001" and it comes up several places including Sears automotive; it does appear to be the correct hub.
Also, the bolts holding my hubs on were Torx 50 bolts and I had to use a 3/8 ratchet extension to reach them. You will definitely need a tool to turn back the brake caliper pistons a bit as well to reinstall the calipers, there is a tool specifically for this purpose but I used a pair of pliers that fit into the notches and took turns alternating between turning and pushing.
I googled "GMB 713-0001" and it comes up several places including Sears automotive; it does appear to be the correct hub.
Also, the bolts holding my hubs on were Torx 50 bolts and I had to use a 3/8 ratchet extension to reach them. You will definitely need a tool to turn back the brake caliper pistons a bit as well to reinstall the calipers, there is a tool specifically for this purpose but I used a pair of pliers that fit into the notches and took turns alternating between turning and pushing.
The following users liked this post:
Vic Douse (04-25-2013)
