XJ6 1997 seat electrical seat motor
#1
![Default](/forum/images/icons/icon1.gif)
Father's-in-law Jaguar he purchased 3 years ago, his seat wont adjust fore and aft. I read most of the thread on this subject.
I found a small yellow connector (bottom right on the picture) with a broken wire under the seat (Eureka moment!) Did repaired it, But I guess it was not the right one. I could not find what is was for, since I didn't tried all the functions before...
I believed I found the right connector for the motor itself, (left one the picture) but ran out of time to check if any power gets to it. There is a "click" from the black "controller" box under the seat when the switch is activated. Easy to remove the seat to get to the motor? Any way to salvage it if it's toast?
Thank you,
Salo
![Name: Jag003-1.jpg
Views: 689
Size: 55.3 KB](https://www.jaguarforums.com/forum/attachments/xj-xj6-xjr6-x300-26/191546d1501327596-xj6-1997-seat-electrical-seat-motor-jag003-1.jpg)
I found a small yellow connector (bottom right on the picture) with a broken wire under the seat (Eureka moment!) Did repaired it, But I guess it was not the right one. I could not find what is was for, since I didn't tried all the functions before...
I believed I found the right connector for the motor itself, (left one the picture) but ran out of time to check if any power gets to it. There is a "click" from the black "controller" box under the seat when the switch is activated. Easy to remove the seat to get to the motor? Any way to salvage it if it's toast?
Thank you,
Salo
![Name: Jag003-1.jpg
Views: 689
Size: 55.3 KB](https://www.jaguarforums.com/forum/attachments/xj-xj6-xjr6-x300-26/191546d1501327596-xj6-1997-seat-electrical-seat-motor-jag003-1.jpg)
#2
![Default](/forum/images/icons/icon1.gif)
Any luck with the seat? I have the same problem currently. I just finished swapping out the seat control modules from the passenger side to the drivers side as they are interchangable but no luck. The seats are easy to remove with a torx bit on the 4 corners, But if yours is in the back position like mine it seems to be imposible to get to the rear two bolts. If anyone knows how to manually move the seat forward so I can remove the seat to continue the repair please let me know. Let me know if you have any progress with yours!
#3
![Default](/forum/images/icons/icon1.gif)
No luck ,and I my father il law is back to his house, I live quite a distance from his home, but I will be dropping in this month.
I believe I can remove the seat, since it's not all the way back. I will try to swap the motor from the passenger side. But first I will check to see if any power get to the motor itself.
Found a few workshop and repair manual on Ebay. It will be easier to troubleshoot.
It may take a while but I will report my progress here.
Hope this DVD is legit...
![Name: 123185961_tp.jpg
Views: 345
Size: 15.2 KB](https://www.jaguarforums.com/forum/attachments/xj-xj6-xjr6-x300-26/191537d1501327581-xj6-1997-seat-electrical-seat-motor-123185961_tp.jpg)
Salo
I believe I can remove the seat, since it's not all the way back. I will try to swap the motor from the passenger side. But first I will check to see if any power get to the motor itself.
Found a few workshop and repair manual on Ebay. It will be easier to troubleshoot.
It may take a while but I will report my progress here.
Hope this DVD is legit...
![Name: 123185961_tp.jpg
Views: 345
Size: 15.2 KB](https://www.jaguarforums.com/forum/attachments/xj-xj6-xjr6-x300-26/191537d1501327581-xj6-1997-seat-electrical-seat-motor-123185961_tp.jpg)
Salo
